Neu Dragon Machinery Elektrostapler TKA10-30

3-Wheel Counterbalanced Electric Forklift Truck
TKA Series 3-Wheel Electric Counterbalanced Forklift Truck
Three wheeled electric forklift truck, three wheeled electric counterbalance forklift, 3-wheel electric seated counterbalanced forklift, 3-wheel electric sit-down counterbalanced forklift, three-wheeled battery powered forklift, 3 wheeled counterbalanced electric forklift, 3 wheeled electric fork lift, 3 wheeled counterbalance forklifts, 3-wheel counterbalanced forklift truck, three-wheel electric forklifts, counterbalanced electric forklift truck, 3-wheel battery forklift, counterbalanced battery forklift

Rated Load: 1.0T - 1.5T
Lifting Height: 3.0m - 4.5m
Overall Length: 2265-2370mm
Overall Width: 915 - 1055mm
Fork Size: 920 x 100mm

Applications:
The unique design concept of three wheeled electric counterbalance forklift truck results in a compact, highly manoeuvrable truck suitable for a wide range of applications: such as storage/retrieval, block stacking and pallet transfer duties.

Features:
1. Safety device for neutral position to prevent electric forklifts from starting when it is in a neutral position to enhance its security;
2. Safety control for cornering, the electric pallet stacker will automatically slow down when cornering;
3. Safety Fuel Oil Shutoff Valve to guarantee the operator and goods in good condition;
4. Forward cylinder safety locks and variable wheelbase to ensure safety when forklift is running;
5. High strength overhead guard to protect the operator;
6. Drive units arranged in parallel to minimize power consumption;
7. Hydraulic power steering to reduce fatigue;
8. Ergonomic multi-functional operating handle and comfortable soft seat to enhance operator comfort and reduce fatigue.

Technical Specifications:
Model: TKA10
Power Type: Electric
Operation Type: Seated
Rated Load Capacity: 1000kg
Load Center: 500mm
Wheel (Tyre) Type, Front/Rear: Solid Rubber/Polyurethane
Front Wheel (Tyre): Φ305×127
Rear Wheel (Tyre): Φ267×127
Number of Wheels, Front/Rear (X=Driving): 2 / 1X
Mast Tilt Angle (Forward/Backward): 2/4deg.
Standard Lifting Height: 3000mm
Free Lift: /
Height of Mast Lowered: 2065mm
Height of Mast Extended: 3560mm
Height of Overhead Guard: 1965mm
Height from Seat to Overhead Guard: 1000mm
Ground Clearance, below Mast: 90mm
Ground Clearance, Center of Wheelbase: 90mm
Overall Length: 2265mm
Length to Fork Face: 1345mm
Wheelbase: 880~961mm
Front Overhang: 175mm
Overall Width: 915mm
Front Wheel Tread: 747mm
Fork Dimensions (L*W*T): 920*100*35mm
Fork Spread: 220~548mm
Aisle Width with 1000*1200 Pallet across Forks: 2690mm
Aisle Width with 800*1200 Pallet along Forks: 2515mm
Min. Turning Radius: 1170mm
Max. Travel Speed (Full-load/No-load): 6.5/7.5km/h
Lifting Speed (Full-load/No-load): 125/170mm/s
Max. Gradeability (Full-load/No-load): 8/10%
Drive Motor: 2.3kW (AC)
Lift Motor: 3.5kW (DC)
Battery: 24V/360Ah
Battery Weight: 295kg
Service Weight (with Battery): 1950kg
Type of Steering: Hydraulic
Service Brake: Hydraulic
Parking Brake: Mechanical

Note:
1. Technical specifications are for standard models only.
2. Other optional accessories and requirements are available upon request.
3. All specifications and design characteristics are subject to change without prior notice.
