Neu Dragon Machinery Dieselstapler CPCD50

5000kg capacity diesel fired forklifts, 5.0T internal combustion forklift, 5.0 ton internal combustion forklift, 5T internal combustion fork lift truck, 5.0 ton counterbalance diesel forklift truck, 5.0T counterbalanced diesel forklifts, 5.0T diesel forklift, 5.0T diesel forklift truck, 5.0 ton diesel forklift, 5.0T capacity diesel forklift, 5.0T diesel fork lift truck, 5.0T diesel powered forklift, 5.0 ton diesel powered forklift, 5.0T diesel fired forklift truck, diesel fired forklift 5.0T capacity, 5 ton diesel forklifts, 5 ton diesel fork lift, diesel fork lift truck 5T capacity, 5000kg diesel forklift truck, 5000kg capacity diesel forklift truck, diesel powered forklift truck 5000kg capacity

Features:
1. Intelligent Drive-monitoring System
The digital intelligent drive-monitoring system of our diesel forklift truck can facilitate obtaining the operation data of the diesel forklift easily, so as to achieve the whole-process control of the forklift.
2. Full Hydraulic Flexible Steering System
The full hydraulic steering system of our diesel forklifts can greatly reduce the fatigue of the operator. The steering system uses a horizontal oil cylinder on the compact steering axle and guarantees a reliable steering.
3. Classical Space Frame Structure
Our diesel forklift truck uses the classical YTO ASF space frame structure. It is ergonomically designed, aesthetic in appearance, compact in structure, and easy to operate.
4. Good Rear-view Visibility
The big arc design of the counterweight can improve the visibility of rear view and guarantee the optimum visibility when driving reversely.
5. Good-view Mast
The optimized rail section design of the mast enables the driver to enjoy a good and wide view.

Technical Specifications:
Model: CPCD50
Power Type: Diesel
Rated Capacity: 5000kg
Load Center: 600mm
Lifting Height: 3000mm
Mast Tilt Angel (F/R): 6/12 deg.
Front Overhang: 590mm
Wheel Base: 2250mm
Wheel Tread (F/R): 1470/1700mm
Dead Weight: 8100kg
Free Lift Height: 195mm
Min. Turning Radius: 3300mm
Min. Ground Clearance - Under Mast: 195mm
Min. Ground Clearance - Wheelbase Center: 200mm
Service Brake: Hydraulic Foot Pedal
Parking Brake: Mechanical Hand Lever
Lifting Speed (full-load): 350mm/s
Lowering Speed: Full-load < 600mm/s, No-load > 300mm/s
Travel Speed (no-load): 21km/h
Max. Gradeability (full-load): 20%
Max. Tractive Force (no-load): 42/32kN
Weight Distribution with load (F/R): 11380/1720kg
Weight Distribution without Load (F/R): 3740/4360kg
Engine Model: LR4B3-24
Engine Manufacturer: YTO
Engine Rated Power: 64kW/2400rpm
Max. Torque/rpm of Engine: 288N•m/1700rpm
Engine Displacement: 4.578L
Battery Voltage: 24V
Battery Capacity: 2X100Ah
Gearbox Transmission Type: Hydraulic torque converter
Gear Shift (F/R): II/II
Tyre Type: Pneumatic Tyres
Tyre Model - Front: 8.25-15-14PR
Tyre Model - Rear: 8.25-15-14PR
Fork Dimension: 60x150x1220mm
Overall Length (without fork): 3510mm
Overall Width: 1995mm
Overall Height - Mast Extended: 4365mm
Overall Height - Mast Lowered: 2500mm
Overall Height - Overhead Guard: 2470mm

Note:
1. Technical specifications are for standard models only.
2. Other optional accessories, functions and requirements are available upon request.
3. All specifications and design characteristics are subject to change without prior notice.

Optional Engine:
Model: 6BG1
Manufacturer: ISUZU
Rated Power: 82.4kW / 2000rpm
Max. Torque: 415N•m /1400rpm
Displacement: 6.49L
